MASTERCELL Polling Video

We pack a ton of powerful diagnostic tools into our Infinitybox 20-Circuit Kit.  With no tools, you can use the inSIGHT screen on the MASTERCELL to learn about everything that is going on in your car’s electrical system.  There is no other wiring harness on the market that can get you that power.

We just published another video going through the specifics of the built-in troubleshooting and diagnostic tools in your Infinitybox system.  This new video covers Polling the system from the MASTERCELL.  When the MASTERCELL power up, it takes an inventory of all of the cells on the CAN network.  This includes your POWERCELLs, inMOTION Cells, inVIRONMENT cells and inTOUCH NET.  From the MASTERCELL screen, you can easily check to make sure that all of the cells are properly communicating on the CAN network.

You can also dig deeper into each cell by polling it from the MASTERCELL screen.  By polling the POWERCELLs, you can get a measurement of the battery voltage measured locally at the POWERCELL.  You can also get a reading of the temperature of the POWERCELL.  You also get a measurement of the Charge Pump voltage on the POWERCELL.  This is a safety system that we monitor to make sure that the POWERCELL is operating correctly.  Lastly, you can get a picture of which outputs are on and off on the POWERCELL.

If you poll the MASTERCELL, you can get a real-time status of all of the switches that are connected.  This is really helpful for troubleshooting and checking your switches as you wire them to the Infinitybox system.

You can watch the new video that goes through polling the system from the MASTERCELL in detail.

You can download our full Diagnostic and Troubleshooting Guide for the 20-Circuit Kit by clicking this link.

You can click on this link if you have any additional technical questions about wiring your car or truck with our Infinitybox system.
