POWERCELL

Our 20-Circuit Kit is the core to the electrical system in your car.  It is more than just a wiring harness.  It is a universal wiring system that gets you the most advanced, functional and reliable electrical control on the market.  The 20-Circuit Kit starts with our MASTERCELL, which connects to your switches.  It also includes two of our POWERCELLs, which we call the muscles of your system.  The MASTERCELL sends commands to the POWERCELLs to locally power your lights, ignition, starter solenoid, cooling fans, fuel pumps, horn and other accessories.  We’ve talked about the MASTERCELL in more detail in a recent blog post.  You can link to that here.  This post is going to cover more details about our POWERCELL.

The 20-Circuit Kit includes 2 POWERCELLs.  Each POWERCELL can control 10-outputs.  One POWERCELL is for the front of the car, the second is for the rear of the car.  The front POWERCELL is set up to control your headlights, high-beams, turn signals, front running lights, horn, cooling fan, ignition power, starter solenoid and dash power.  The rear POWERCELL is set up to control your rear running lights, turn signals, brake lights, fuel pump, back-up lights, dome lights and other accessories.

Connecting your loads to the POWERCELL is very easy.  You run the output harness from the POWERCELL to your light, fan, pump or other accessory.  You cut our universal harness to length.  You connect our output wire to the wire on your load.  That’s it.  Click on this link to get more details on connecting your POWERCELL outputs to the electrical loads in your car or truck.

You put the POWERCELLs in the car were you need them.  This lets you eliminate size and weight of the wiring harness in your car.  The installation is simpler because the runs of wire are shorter and troubleshooting is easier.

The POWERCELL is a remote fuse and solid-state relay box.  The fuses that you need to properly protect your wiring harness are built into the POWERCELL.  You do not need to add separate fuses.  Also, the solid-state relays that control your loads are built into the POWERCELL.  Each output can carry up to 25-amps continuously so you do not need to add external relays to control your lights, fans, pumps and other accessories.  Also, we don’t use mechanical relays in our POWERCELLs.  Our outputs are controlled by solid-state MOSFETs.  This are rugged and reliable and give you tons of benefits over traditional relays.  Check out this link to learn about some of the advantages of a MOSFET.

This video walks through more of the details of the Infinitybox POWERCELL.

You can easily add extra POWERCELLs to your 20-Circuit Kit if you need to expand the output capacity beyond 20.  Each additional POWERCELL gives you 10 more outputs to your Infinitybox system.  The POWERCELL kit includes the POWERCELL plus all of the harnessing required to connect to your existing 20-Circuit Kit.  You can learn more about the POWERCELL kit by clicking this link.

We have the solid model for the POWERCELL available to our customers to help with their planning and mocking up process.

If you want to purchase our Infinitybox system or have technical questions, you can click on this link to contact our team.
